UHF access control antenna narrow beam rfid directional antenna BRA-08
Consult nowBRA-08 Antenna
BRA-08 Antenna is of convenient application in UHF RFID access control, personnel management, asset management and other application fields.
Electrical Properties: It is a general antenna for terminal applications with directional feature, narrow beam, high gain, miniaturization and etc.
Mechanical Properties: small size and suitable for various access control, vehicle management and etc.
| Frequency Range | 902MHz～928MHz |
| VSWR | ≤1.3:1 |
| Gain | > 6 dBic |
|
Axial ratio |
<3 dB |
| Polarization | Circular Polarization |
| Relative humidity | 5%～95% |
| Impedance | 50±1Ω |
| Connector Type |
SMA-50KFD Female |
| Size | 130mm×335mm×17.55mm |
| Weight | 0.75kg |
| Material |
RF-4, stainless steel |
| Color |
silvery white |
| Production Class | Indoor use |
| Operating Temperature | -40℃~+ 85℃ |
| Storage Temperature | -40℃~+ 85℃ |
Figure 1. Antenna Photo
