Electrical performance: It is a general-purpose antenna suitable for UHF band RFID applications with high gain and narrow beam.
Mechanical properties: suitable for a variety of harsh environments.

Main use and scope of application

The BRA-21 antenna can be easily applied to applications such as vehicle management and asset management in the UHF band.

Performance Specifications

Mechanical Specifications

Figure 1. Antenna Photo

Mounting

The BRA-21 antenna can be mounted on the steel frame structure or pillar by its own bracket or user-fitted bracket, and connected to the reader through the coaxial cable. The antenna can be installed horizontally or vertically, depending on the mounting orientation of the bracket. After installation, the tilt angle of the antenna can be adjusted according to the actual situation.
The antenna mount is an option and the customer can choose as needed.

Antenna pattern
