With the development of library management information, traditional book management methods and technical means have always restricted the development of the library management industry. RFID technology is applied to libraries, which can realize the functions of fast and reliable borrowing of books, quick inventory, search, and collation of books. RFID electronic tags are used as information storage media and pasted on books. The basics of storing the books in RFID chips are Information and borrowing records, using RFID reading and writing equipment, in conjunction with the back-end database management system, can realize library information management, greatly improve the intelligent level of library management, improve work efficiency, and reduce the labor intensity of library managers. It has brought revolutionary improvement to library information management.
The product uses a steel structure, the smallest unit is a double-sided six-layer design, each floor can hold about 50 books, multiple units can be spliced into columns. A touch screen is installed on the side of the spliced bookshelf to display the information of the books on the entire shelf, and the location of the bookshelf where the books are located can be retrieved by connecting to the network. The special antenna for product configuration can effectively avoid misreading the book labels on the upper and lower sides, the front and back, the left and right adjacent layers or the adjacent bookshelves of the layer, and can realize the recognition success rate of the book without the magnetic stripe being more than 99%. Has the following features:
□ Independent intellectual property design
□ With Linux operating system
□ Support EPC C1 G2 (ISO18000-6C) agreement
□ Output power up to 33dbm, adjustable power (range 8 dBm -33dBm)
□ Have registration, inventory, and inquiry functions
□ With the shelf area (one area in the middle of the two book boxes) positioning function
□ The typical spacing of the regional spacing is 195mm, and the optional precision is 90mm.
□ Ensure that there are no misinterpretations between the bookshelves, with a shelf spacing of up to 0.8 m and a typical value of 1.2 m.
□ The inventory rate is fast, and the inventory time of 96 areas can be as fast as 8 seconds.
□ Real-time inventory function can be realized, and books can be found in real time.
□ The port dwell time is freely set in units of 10ms (typically 50ms), which can adapt to more application requirements.
□ Easy secondary development, providing a complete API interface
□ Built-in eight-way optical isolation GPIO port for more application needs
UHF RFID technology has the characteristics of long reading distance, fast recognition speed, good penetrability, strong multi-tag recognition ability and high recognition accuracy. The intelligent bookshelf based on UHF rfid technology can realize fast and reliable borrowing of books, fast inventory, search, Information management such as organizing books and collating, effectively improving the efficiency of library management and realizing the "digital library" in the true sense.
